3 Axle 60 Ton 100 Ton 18 Meter Lowboy Axle Low Bed Truck Lowbed Semi Trailer. We're one of China's leading Low Bed Trailer manufacturers, equipped with a productive factory. All products for sale enjoy competitive price and one year warranty.
Chat Now

Product Details


low-bed-trailer

lowbed  (1)

Specification
Overall Dimension
13000x3000x1650mm
Working Deck Dimension
9000x3000x1350mm
Platform thickness
4mm
Main Beam
“H”main beam design,Q345B carbon steel,
the height of the beam is 500 mm,
upper plate is 16mm,down plate is 18mm, middle plate is 10 mm.
Wheelbase
7,650mm+1,310mm+1,310mm
Payload
60,000kg
Tare weight
9,000kg
G.V.W.R.
69,000kg
Axle
3X13Ton, FUWA brand
one hundred fifty thousand Kilometers no need maintenance
Tire
1100R20, 12 pcs
Rim
8.0*22.5  10 holes ISO, 12 pcs
Suspension system
Mechanical Suspension
Brake system
Dual line pneumatic brake, SAE hose and connector,optional ABS
Brake air chamber
6 units T30/30 spring brake chambers
Emergency relay valve
Wabco relay valve
Traction/King Pin
2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster
Landing Gear
28ton external two speed telescopic manual operation
Ramp
Heavy duty trailer ramp
