Product Details

Product Description:

Clients often use our flatbed trailers to carry large construction equipment and other cargo that cannot be placed inside other type of semi trailers.

We are responsible for safely loading and unloading the flatbed trailer, while making sure the equipment is safe as well.

20ft flatbed trailer

Dimension and Weight
Overall Dimension(mm)	12500x2500x1650mm
Wheelbase	7,500mm+1,310mm+1,310mm
Payload	40,000kg
Tare weight	6,500kg
G.V.W.R.	46,500kg
Function	transport 1x20ft, 2x20ft, 1x40ft container
Running System
Main beam	height of the beam is 500mm, upper plate is 14mm, down plat is 16mm, middle plate is 8mm.
Side beam	16#
Axle	3x13Ton ZY brand
Axle Number	Three
Tire	12R22.5, 12 pcs. Taitong brand
Rim	9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs
Suspension system	Mechanical Suspension
Steel Spring	10/10/10 leaf spring with 90mm(W) *13mm(thickness)
Electrical System	Chinese standard 24V lighting system
Brake system	Dual line pneumatic brake, no ABS
Brake air chamber	6 units T30/30 Double brake chambers
Emergency relay valve	Standard
Diamond plate	4mm
Traction/King Pin	2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster
Landing Gear	Yahua brand 28ton external two speed telescopic manual operation 2,500mm behind the kingpin location
