3 Axle 40 Foot Flatbed Semi Trailer
Product Details
3 axle 40 foot flatbed semi trailers are a heavy-duty transport tool that usually handles wide loads, oversized equipment, machinery, and bulk cargo. They are made of heavy steel and usually have multiple axles to safely move heavy cargo. Flatbed trailers are suitable for safely storing cargo containers of various sizes, and they are often used as the preferred mode of transportation between shipping terminals.
Why choose our flatbed trailers?
1. Frame: The frame is made of high-quality low-alloy high-strength steel plates, and the space frame structure uses welded longitudinal beams and integral through beams. The reasonable structure improves the strength, rigidity, radial and other properties of the frame, and has the characteristics of lightweight and strong load-bearing capacity.
2. Axles: The axles use imported or domestic high-quality axles, such as BPW, FUWA, CIMC, etc., which have the advantages of large load-bearing capacity and long service life. At the same time, ABS systems of well-known domestic and foreign brands such as Haldex and WABCO can be installed to maximize the stability and safety of the vehicle.
3. Braking system: adopts a safe and reliable dual-circuit pneumatic brake system, equipped with energy storage slave cylinder, Haldex optional. Imported or domestic well-known brand relay valves such as WABCO ensure good braking performance.
Application of 3 axle 40 foot flatbed semi trailer
Flatbed semi trailers are mainly used to transport heavy, oversized, wide, and non-breakable goods, such as machinery, building supplies, or equipment. For example: transporting construction equipment, building and construction materials transportation, scrap metal and recyclables mobilization, oil and gas drilling platform transportation, agricultural equipment, and cargo transportation.
Specifications of 3 axle flatbed semi trailer
| Trailer Model | 3 Axle Flatbed Trailer |
| Overall Dimension(L x W x H)(mm) | 12500 * 2500 * 1600 |
| Loading Weight | 40000kg |
| Axle | 3*13Ton Axle |
| Main Beam | Q345 carbon steel, the height of the main beam is 500mm, the upper plate is 14mm, the down plate is 16mm, the middle plate is 8mm |
| Platform Plate | 3mm Diamond plate |
| Side Beam | Q235 16# channel steel |
| Suspension System | Mechanical Leaf Spring Suspension |
| Leaf Spring | 90(W)mm*13(Thick)mm*10Layer |
| Container Twist Locker | 12pcs container locker |
| Tire Type and Quantity | 12R22.5 12units |
| King Pin | 50#/90# |
| Spare Wheel Bracket | 2pieces |
| Tool Box | 1 standard |
| Landing Gear | Standard 28ton single action supporting legs |
| Brake System | Dual line braking system |
| Brake air chamber | six double chamber |
Packaging and transportation
Why choose us?
1. Factory direct sales: We have a professional team of engineers to design 3 axle 40 foot flatbed semi trailers according to customer requirements, taking full account of working conditions.
2. Our products can be customized according to various needs. And provide customizable unique company logos.
3. The factory uses the most advanced automation equipment. The steel is welded using an automatic submerged arc process, and the connection points look better, are stronger, and are more durable than those made using the traditional manual method.
4. The cover spray painting is more sustainable, corrosion-resistant, uniform, and smooth, and adopts a sandblasting powder spray painting process.
Customer Visit
Relying on high-quality products, good reputation, and high-quality services. We sincerely hope to cooperate with domestic and foreign merchants for mutual benefit and create a better future, and at the same time develop together and create a better future!
