45 Foot Flatbed Semi Trailer
Product Details
45 foot flatbed semi trailers are specially designed for transporting a variety of containers. They feature a rational structure, reliable operation, and attractive appearance, unleashing the vehicle's full potential. A wide range of models is available to meet individual customer needs.
Features of 45 foot flatbed semi trailer
1. Load Capacity: Flatbed semi-trailers have excellent load capacity, and their sturdy chassis and high-quality materials ensure safety and stability during transport.
2. Versatility: The open design of flatbed semi-trailers adapts to various cargo transport needs and can be securely loaded using simple fastenings.
3. Convenience: 45 foot flatbed semi trailers are typically equipped with adjustable legs and a flexible connection system, facilitating quick loading and unloading and connecting to tractors.
Applications of 45ft flatbed semi trailer
Flatbed semi trailers are highly efficient vehicles widely used in the logistics and transportation industries, particularly for transporting large equipment, construction materials, machinery, and other heavy cargo.
Specifications of 45ft flatbed semi trailer
Our engineers will design the configuration according to customer requirements. We select reliable tires, such as Triangle and Linglong, from renowned Chinese brands, which are also optional. We also use well-known axle brands such as Fuwa and BPW.
| Trailer Model | 3 Axle Flatbed Trailer |
| Overall Dimension(L x W x H)(mm) | 12500 * 2500 * 1600 |
| Loading Weight | 40000kg |
| Axle | 3*13Ton Axle |
| Main Beam | Q345 carbon steel, the height of the main beam is 500mm, the upper plate is 14mm, the down plate is 16mm, the middle plate is 8mm |
| Platform Plate | 3mm Diamond plate |
| Side Beam | Q235 16# channel steel |
| Suspension System | Mechanical Leaf Spring Suspension |
| Leaf Spring | 90(W)mm*13(Thick)mm*10Layer |
| Container Twist Locker | 12pcs container locker |
| Tire Type and Quantity | 12R22.5 12units |
| King Pin | 50#/90# |
| Spare Wheel Bracket | 2pieces |
| Tool Box | 1 standard |
| Landing Gear | Standard 28ton single action supporting legs |
Packaging and Shipping
We typically ship 45 foot flatbed semi trailers in three ways: bulk carrier, roll-on/roll-off (RORO) vessel, and 40' flatbed.
