3 Axles 45000 Liters Petrol Tank Semi Trailer
Product Details
The 3 axles 45000 liters petrol tank semi trailer is engineered for the high-capacity, safe bulk transport of volatile fuels, particularly unleaded and premium petrol (gasoline), diesel, and aviation fuel.
Designed with advanced anti-explosion safety systems, internal wave-proof baffles, and customizable multi-compartment layouts, this 45,000-liter petrol tanker provides hazardous liquid transporters with max payload efficiency, strict leak prevention, and stable highway performance across Africa, Southeast Asia, the Middle East, and South America.
Main specification
|
Trailer Model |
3 Axles 45000 Liters Petrol Tank Semi Trailer |
|
Overall Dimension |
11100x2500x3600mm |
|
Function |
transport Fuel, Oil, Diesel |
|
Thickness(mm) |
Tank body: Q235 carbon steel 5mm |
|
Loading(L) |
45, 000 |
|
Axle Brand |
FUWA Brand 13Ton Axle |
|
Axle Number |
Three |
|
Compartment |
2 or 3, it is optional |
|
Manhole cover |
Standard 500mm |
|
Discharge valve |
4" |
|
Emergency valve |
4" |
|
Suspension |
Mechanical suspension |
|
Main beams |
Opting for high tensile steel Q345B welded by automatic submerged-arc processes |
|
The material of Main beam |
The height of the beam is 500 mm, upper plate is 14mm, down plate is 16mm, middle plate is 8mm |
|
Tire Tire and quantity |
12R22.5 triangle brand 12units |
|
Traction Pin |
2' or 3.5' optional |
|
Spare Wheel Bracket |
2 pieces |
|
Tool Box |
1 Standard |
|
Landing Gear |
28ton |
|
Brake system |
Break system：double line air breaks with spring loaded parking brake,air parking brake |
|
Brake chamber |
6 relay valve; T30/30+T30 Spring brake chamber; one piece of 45L air tanks |
|
air chamber |
Six big double air chambers |
|
Bumper |
heavy-duty bumper at the rear |
|
Loading |
bottom and top loading |
|
Electrical light |
electrical equipment 24 Volt,in accordance with the road traffic regulations electric connection type SAE 7 poles mounted on the front bearer. |
|
Walkway |
for easy access to manholes covers(material is carbon steel) |
|
Access ladder |
one(1) access ladder at front of tank. |
Key Features & Advantages
1. High-Safety Explosion-Proof & Vapor Recovery System: Because petrol generates volatile vapor, each compartment features explosion-proof manhole covers, emergency pressure-relief breathing valves, and an optional Vapor Recovery System (VRU). This captures petrol fumes during loading and unloading, reducing fuel loss, environmental pollution, and fire risks.
2. Wave-Proof Anti-Surge Baffles: Built with internal wave-dampening baffles welded at regular intervals. These baffles absorb the powerful surge impact of liquid petrol during rapid braking, acceleration, or sharp turns, maintaining a low center of gravity and excellent towing stability.
3. Pneumatic Emergency Bottom Shut-off Valve: Every compartment outlet is fitted with an air-operated emergency cut-off valve at the bottom of the tank. In the event of a collision or piping damage, the pneumatic valve automatically cuts off the petrol flow within seconds, preventing major leaks and spill hazards.
4. Anti-Static & Spark-Free Protection: Equipped with heavy-duty static grounding reels, conductive rubber hoses, and non-sparking copper discharge fittings to safely dissipate static electricity built up during rapid fuel flow.
Applications & Operating Scenarios
1. Petrol Station Supply Networks: Designed for oil marketing companies and transport contractors supplying multiple grades of petrol and diesel to commercial fuel stations in single high-volume shipments.
2. Airport & Aviation Fuel Logistics: Configurable with stainless steel or aluminum alloy tanks to transport aviation petrol (Avgas) and jet fuel without oxidation or rust contamination.
3. Mining & Heavy Fleet Fuel Depots: Built on a heavy-duty steel chassis with reinforced suspension to deliver bulk petrol to remote mining camps, construction fleet depots, and power generator sites over unpaved roads.
Why Source Petrol Tanker Trailers from Our Factory?
Rigorous Leakage & Hydrostatic Testing: 100% of our petrol tanks undergo 24-hour liquid pressure and airtightness testing before painting.
Lightweight Aluminum Option: We offer high-grade aluminum alloy tank bodies to reduce tare weight, allowing up to 10% more petrol payload within legal axle weight limits.
Seaworthy Anti-Rust Treatment: Frame and tank undergo complete shot-blasting, anti-corrosion primer coating, and marine-grade polyurethane finish to prevent saltwater corrosion during shipping.
Full Range of Spare Parts: Long-term factory availability of API adapters, discharge valves, manhole seals, and pneumatic control valves.
