Crude Oil Tanker Semi Trailer
Mob/Whatsapp/Wechat:+86-18253112966
E-mail:cdtruck@sinotrucksale.com
Product Details
Compared with the traditional single-tank tanker, the use of crude oil tanker semi trailer transportation can effectively improve transportation efficiency. In the case of the same tonnage, the transportation cost is reduced and the fuel consumption is saved.
Features of crude oil tanker semi trailer
1. The tank body is made of 4mm or 6mm high-quality carbon steel according to national standards. The shape of the tank body is divided into oval or square round tank bodies, which can contain 1-4 kinds of oil products. It can also produce heating and heat preservation series tanks.
2. Alcohol and chemical tank trucks at home and abroad are made of high-quality stainless steel with a thickness of 4mm to 5mm.
3. Various hydrochloric acid, sulfuric acid, and lye tank trucks are made of plastic with a thickness of 12 mm to 22 mm.
4. Multiple anti-wave baffles are set inside the tank. A high-pressure gas leakage test is adopted to ensure high tank strength, a stable center of gravity, and safe and stable vehicle transportation.
Specification of crude oil tanker semi trailer
| Tank body part | |
| Shape | Round or Square (Optional) |
| Dimension | 9500-13000*2500*3900mm |
| Tare Weight | About 8000kgs-12800kgs |
| Capacity | 32,000-60,000 liters |
| Tank body material | 5mm or 6mm Q235 Carbon steel / Aluminum alloy / Stainless steel |
| Dished End | 6mm or 7mm Q235 Carbon steel / Aluminum alloy / Stainless steel |
| Manhole Cover | Carbon steel/ aluminum/ stainless steel manhole cover, diameter 500mm, 1-9 pieces |
| Bottom Valve | Aluminum / Stainless steel |
| Discharging Valve | Diameter 3" or 4" or 6" |
| Compartments | Optional |
| Discharging hose | Rubber tube, 2 pieces, 6 m each |
| Chassis part: | |
| Main beams | Steel Q345B or Aluminum Alloy |
| Axle | 13T/16T, FUWA brand |
| Kingpin | 50#/90# optional, JOST brand for option |
| Suspension | Mechanical suspension/Air suspension |
| Leaf spring | 90mm (W) * 13mm (T)* 10 layer or 100mm *12mm *12 layer |
| Braking system | RE 6 relay valve, spring brake chamber, 2 pieces of 45 L air tanks |
| Tire | 12R22.5 295/80R22.5 315/80R22.5 11.00R20 12.00R20 |
| Rim | 9.00*22.5/8.0-20/8.5-20 |
| ABS | WIth or without ABS for option |
| Spare tire carrier | 2 pieces |
| Safety guard | Standard |
| Painting | Complete chassis sand blasting to clean rust, 1 coat of anti-corrosion primer, 2 coats of final painting |
| Tool box | One pieces standard |
| Lights | LED, 24V |
| Shipping terms | By 40" HQ container or bulk vessel or RORO ship |
Packaging and Shipping
Chengda gasoline transport truck trailer is usually adopted by bulk carriers or ro-ro ships. We spray wax on the tank. Cover it with a tarp. Some countries can also ship by container or frame cabinet
Pre-sale service
1. Our products can be customized according to your needs. A variety of styles for your choice.
2. Good quality + factory price + fast response + reliable service, is what we try our best to provide for you.
3. All of our products are produced by our professional workers, we have a high-efficiency foreign trade team, and you can fully trust our services.
After-sales service
Our company promises a one-year warranty period, calculated from the date customers receive our products. Under normal use, if the accessories are damaged, we will provide customers with free new accessories. We provide lifetime maintenance and lifetime technical support for our crude oil tanker semi trailers. After the one-year warranty period, we only charge for the parts that need to be replaced, with no other additional fees.
