Sinotruk HOWO Concrete Mixer Truck
Truck Brand: SINOTRUK-HOWO
Driving Type: 6x4
Dimension (LxWxH):8980×2500×4000mm
Product Details
SINOTRUK HOWO concrete mixer truck maintains the mixing of concrete when transporting concrete or at the construction site to maintain the consistency of concrete, prevent initial solidification and separation during transportation, ensure pouring quality and reduce concrete loss.
CHINA SINOTRUK HOWO 6X4 cheap 336hp 10 wheeler 8M3 9CBM 12M3 concrete mixer tank truck with Eaton pump also called a truck mixer, is used to transport concrete in the building ground and the highway project, According to clients' requirements, We can customize different horse power and cubic meters.
Specification | |
Model | ZZ1257M3847 |
Truck Brand | SINOTRUK-HOWO |
Driving Type | 6x4 |
Dimension (LxWxH) | 8980×2500×4000mm |
Approaching angle/Departure angle (°) | 16/22 |
Overhang (front/rear) | 1500/2340 |
Wheelbase (mm) | 3800+1400 |
Wheelbase (mm) | 4600+1350 |
Engine Model | WD615 93C |
Fuel type | Diesel |
Fuel tanker capacity | 300 |
Horse Power | 290HP |
Emission | EURO III |
Fuel type | Diesel |
Transmission | HW13710 |
Service brake | Dual circuit compressed air brake |
Parking brake | spring energy, compressed air operating on rear wheels |
Auxiliary brake | Engine exhaust brake |
Steering system | ZF8098 |
Front axle | HF9 |
Rear axle | HC16 |
Color | Optional |
Tire and Tire quantity | 12.00-20/10+1 spare |
Electrical system Battery | 2X12V/165Ah |
Alternator | 28V-1500kw |
Starter | 7.5Kw/24V |
Cab | HOWO76 cab, (single sleeping, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's sea |
Features of SINOTRUK HOWO concrete mixer truck
1. On the basis of in-depth and comprehensive research on the industry, XCMG's new generation of truck mixers adopts integrated modular design and system optimization to truly realize integrated innovation.
2. Special stirring technology with continuous tracking, original double logarithmic screw technology, variable lifting angle and variable screw pitch, optimized auxiliary blade, and decompression hole design, which can make the operating path of the screw in perfect condition. condition and ensures optimum concrete flow trends and more uniform discharge in the mixing drum.
3. Dual output control, lightweight technology, and anti-scatter technology make the vehicle more environmentally friendly and more effective.
4. Optimize the chassis and upper parts, front base and accessory beam, rear base and inclined beam, rear base, and accessory beam, and other parts to adopt an integrated design. After the force research analysis and long-term application, the optimal position of the connection point between the inclined beam and the rear base was confirmed, thus effectively avoiding the deformation and fracture of the beam.
5. Hydraulic transmission system of international brands: Hydraulic pumps, motors, and reducers of world-renowned brands such as ZF, Rexroth, Bonfiglioli, PMP, and TOP are used to make the power more sufficient, the system more stable and reliable, and the service life longer.

Packing and Shipping
The concrete mixer tank truck is usually shipped in the Bulk ship, RORO ship, and flat rack
Container. RORO Ship: The truck is driven into the ship directly. We will choose the best and the safest way according to your requirement.

FAQ
1: Who are you?
A: Chengda Group was established in 2005 and is one of the qualified manufacturers of various types of trailers. With high-standard machinery and automation equipment, a strong R&D team, and an elite sales team, we have established long-term business relationships with Sinotruk/SHACMAN/FAW/Dongfeng truck brands.

2: What payment terms are acceptable?
A: Usually we can use T/T terms or L/C terms.
3: Which incoterms 2010 terms can we use?
A: Usually we work with FOB, CFR, and CIF as standard.

4: What about the delivery time?
A: 7-30 days after receiving the deposit.
5: What about the warranty time?
A: 12 months or 2000 working hours after shipment.
6. What is the MOQ?
A: The MOQ is 1 piece.
Any questions, feel free to contact me.
