Sinotruk HOWO Concrete Mixer Truck

Model: ZZ1257M3847

Truck Brand: SINOTRUK-HOWO

Driving Type: 6x4

Dimension (LxWxH):8980×2500×4000mm
Chat Now

Product Details

SINOTRUK HOWO concrete mixer truck maintains the mixing of concrete when transporting concrete or at the construction site to maintain the consistency of concrete, prevent initial solidification and separation during transportation, ensure pouring quality and reduce concrete loss.


CHINA SINOTRUK HOWO 6X4 cheap 336hp 10 wheeler 8M3 9CBM 12M3 concrete mixer tank truck with Eaton pump also called a truck mixer, is used to transport concrete in the building ground and the highway project, According to clients' requirements, We can customize different horse power and cubic meters.

Specification

Model

ZZ1257M3847

Truck Brand

SINOTRUK-HOWO

Driving Type

6x4

Dimension (LxWxH)

8980×2500×4000mm

Approaching angle/Departure angle (°)

16/22

Overhang (front/rear)

1500/2340

Wheelbase (mm)

3800+1400

Wheelbase (mm)

4600+1350

Engine Model

WD615 93C

Fuel type

Diesel

Fuel tanker capacity

300

Horse Power

290HP

Emission

EURO III

Fuel type

Diesel

Transmission

HW13710

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

ZF8098

Front axle

HF9

Rear axle

HC16

Color

Optional

Tire and Tire quantity

12.00-20/10+1 spare

Electrical system Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

HOWO76 cab, (single sleeping, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's sea


Features of SINOTRUK HOWO concrete mixer truck

1. On the basis of in-depth and comprehensive research on the industry, XCMG's new generation of truck mixers adopts integrated modular design and system optimization to truly realize integrated innovation.


2. Special stirring technology with continuous tracking, original double logarithmic screw technology, variable lifting angle and variable screw pitch, optimized auxiliary blade, and decompression hole design, which can make the operating path of the screw in perfect condition. condition and ensures optimum concrete flow trends and more uniform discharge in the mixing drum.


3. Dual output control, lightweight technology, and anti-scatter technology make the vehicle more environmentally friendly and more effective.


4. Optimize the chassis and upper parts, front base and accessory beam, rear base and inclined beam, rear base, and accessory beam, and other parts to adopt an integrated design. After the force research analysis and long-term application, the optimal position of the connection point between the inclined beam and the rear base was confirmed, thus effectively avoiding the deformation and fracture of the beam.


5. Hydraulic transmission system of international brands: Hydraulic pumps, motors, and reducers of world-renowned brands such as ZF, Rexroth, Bonfiglioli, PMP, and TOP are used to make the power more sufficient, the system more stable and reliable, and the service life longer.

Howo concrete mixer truck


Packing and Shipping
The concrete mixer tank truck is usually shipped in the Bulk ship, RORO ship, and flat rack
Container. RORO Ship: The truck is driven into the ship directly. We will choose the best and the safest way according to your requirement.

packing & shipping

FAQ

1: Who are you?

A: Chengda Group was established in 2005 and is one of the qualified manufacturers of various types of trailers. With high-standard machinery and automation equipment, a strong R&D team, and an elite sales team, we have established long-term business relationships with Sinotruk/SHACMAN/FAW/Dongfeng truck brands.

 Our customers

2: What payment terms are acceptable?

A: Usually we can use T/T terms or L/C terms.


3: Which incoterms 2010 terms can we use?

A: Usually we work with FOB, CFR, and CIF as standard.

Certificate

4: What about the delivery time?

A: 7-30 days after receiving the deposit.


5: What about the warranty time?

A: 12 months or 2000 working hours after shipment.


6. What is the MOQ?

A: The MOQ is 1 piece.


Any questions, feel free to contact me.
