3 Axles 45000 Liters Fuel Tanker Trailer Oil Tank Trailer

Trailer Model

3 axles 45000 liters fuel tanker trailer oil tank trailer

Overall Dimension

 11900x2500x3800(Lx W x H)(mm)

Function

transport Fuel, Oil, Diesel

Thickness(mm)

Tank body: Q235/5mm  carbon steel

End plate: Q235/6mm carbon steel

Volume

30000L-60000L

Axle Brand

FUWA 13Ton Axle, top brand

Axle Number

Three

Compartment

3-9compartments

Manhole cover

500mm manhole cover. 3 sets with3 breath valve.

Ladder

Top ladder with handrail, side ladder

Discharge valve

4''disc valve

Discharge pipe

4''seamless steel tube

Suspension system

Leaf spring suspension

Bottom valve quantity

3 units

Steel Spring

10/10/10 leaf spring suspension

90mm width, 13mm thickness

The material of Main beam

The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm,middle plate is 8mm.

Tire Type and quantity

12R22.5  Taitong top brand  12units

Traction Pin

50mm/90mm, jost brand

Spare Wheel Bracket

2 pieces

Tool Box

1 Standard

Landing Gear

Standard brand 28ton external, 2 speed, zhenhua brand

Brake system

Dual Line braking system

Brake air chamber

Six big double air chambers

Electrical system

1. Voltage: 24v   2. Receptacle: 7 ways (7 wire harness)

Tail lamp with turn signal, brake light & reflector, side lamp etc.

One set 6-core standard Cable.

Side Guard

According to customer’s requirement

Painting

According customer requirement

Packing

Polish with wax before shipping
