Chengda 42, 000 Fuel Tanker Trailer with 3 Inch Manhole Cover
Dimension(Lx W xH)(unloaded)(mm) 11950*2495*3900
 Tare Weight(KG) 9000
 Loading Weight( KG) 40000
 Total Weight(KG) 50000
 Tank capacity( CBM ) 45
 Volume(L) 45000
 Medium  Fuel
 specification mechanical or air suspension
 Tank Material carbon steel
 Tank thickness(mm) 6
 Main beam The height of the beam is 500 mm, upper
 plate is16mm,down plate is 18mm, middle
 plate is 10mm.
 Axle  3x13ton,L1 brand axle
 Compartment 3
 Manholes 3
 Spill Discharges 3
 Walkway on the top
 Suspension system Leaf spring suspension
 Steel Spring 10/10/10 air bag suspension
 Tire Type and quantity 1100R20  12units( 1 spare tire)
 Traction Pin 90mm
 Spare Wheel Bracket 2 pieces
 Tool Box 1 Standard
 Landing Gear Standard 28ton
 Brake system Dual Line braking system ,none ABS.
 Brake air chamber Six double chamber
 Electrical system 1. Voltage: 24v   2. Receptacle: 7 ways (7 wire harness)

 Tail lamp with turn signal, brake light & reflector, side lamp etc.

 One set 6-core standard Cable.
 Painting

 Optional
