Product Details



Product Description





our specification for China Sinotruk Howo 8x4 12 Wheeler Front Lifting Dump Tipper truck for sale



 dump truck32





Truck Model

ZZ3317V4667C1   (LHD)

Truck Brand

SINOTRUK –HOWO

Driving Style

Left Hand Driving

Dimension(Lx W x H)(unloaded)(mm)

11240x2496x3451

Cargo body size (L*W*H, mm) (mm)

8000x2300x970

Cargo thickness(mm)

Bottom:8mm, Side:6mm

Lift type of Carriage

Middle side

Approaching angle/Departure angle(°)

19/26

Overhang(front/rear) (mm)

1500/1739

Wheel base (mm)

3625+1350

Max speed(km/h)

75

Maximum gradeability (%)

40

Minimum ground clearance(mm)

314

Minimum turning circle (m)

20

Curb weight(kg)

12290

Loading Weight(kg)

25000

Fuel tanker capacity(L)

300

Fuel consumption(L/km)

28L/100 km

Clutch

Single-plate dry clutch Φ430mm

Engine Model

(Steyr technology)

Fuel type

Diesel


Horse Power,

max(kw/rpm)

420HP,247/2200


Emission

EURO II


Model

D12.42,water-cooled,four strokes,6 cylinders in line with water cooling ,

directly injection


Bore

126mm


Stroke

130mm


Compression ratio

29.8hp/l


Specific fuel consumption

195g/kwh

Transmission

Model

HW19710, 10 forwards and 2 reverse

Brake system



Service brake

Dual circuit compressed air brake


Parking brake

spring energy, compressed air operating on rear wheels




Auxiliary brake

Engine exhaust brake

Steering system



Model

ZF8098 hydraulic steering with power assistance

Front axle

HF9 , Steering with double T-cross section beam

Rear axle

HC16, Pressed axle housing, central double reduction with differential locks between axle

s and wheels

Color

Optional (White ,Red ,yellow )

Tyre

12.00-20  11 units

Electrical system



Battery

2X12V/165Ah


Alternator

28V-1500kw


Starter

7.5Kw/24V

Cab

HOWO76 cab, single sleeper with air conditioner, all-steel forward control,

55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds,

laminated windscreen with casted-in radio aerial, hydraulically damped adjustable drivers seat and rigid adjustable co-drivers seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder,

safety belts and adjustable steering wheel, air horn, with 4-point support

fully floating suspension and shock absorbers
